APC BX1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 900 W 6 AC outlet(s)
Roll over image to zoom inClick to Open expanded view
APC BX1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 900 W 6 AC outlet(s)
APC BX1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 900 W 6 AC outlet(s)
APC BX1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 900 W 6 AC outlet(s)
APC BX1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 900 W 6 AC outlet(s)
APC BX1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 900 W 6 AC outlet(s)
APC BX1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 900 W 6 AC outlet(s)
Print
Model: BX1600MI
EAN: 731304410829

APC BX1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 900 W 6 AC outlet(s)

Manufacturer:
APC
APC BX1600MI, Line-Interactive, 1.6 kVA, 900 W, Sine, 140 V, 300 V
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

APC BX1600MI. UPS topology: Line-Interactive, Output power capacity: 1.6 kVA, Output power: 900 W. AC outlet types: C13 coupler, Power plug: C13 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 1 min, Typical backup time at half load: 6.5 min. Form factor: Compact, Product colour: Black, Cable length: 1.2 m. Width: 140 mm, Depth: 390 mm, Height: 190 mm

Product Properties

  • Manufacturer
  • APC
  • Model
  • BX1600MI
  • EAN
  • 731304410829
  • Battery
  • Battery life (max)
  • 2 year(s)
  • Battery recharge time
  • 8 h
  • Battery technology
  • Sealed Lead Acid (VRLA)
  • Typical backup time at full load
  • 1 min
  • Typical backup time at half load
  • 6.5 min
  • Design
  • Built-in fan
  • Y
  • Cable length
  • 1.2 m
  • Certification
  • CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
  • Form factor
  • Compact
  • International Protection (IP) code
  • IP20
  • LED indicators
  • Y
  • Product colour
  • Black
  • Features
  • Audible alarm modes
  • Low battery alarm
  • Audible alarm(s)
  • Y
  • Automatic Voltage Regulation (AVR)
  • Y
  • Input frequency
  • 50/60 Hz
  • Input operation voltage (max)
  • 300 V
  • Input operation voltage (min)
  • 140 V
  • Input power factor
  • 0.56
  • Noise level
  • 40 dB
  • Output frequency
  • 50/60 Hz
  • Output frequency regulation
  • 0.5 Hz
  • Output operation voltage (max)
  • 230 V
  • Output operation voltage (min)
  • 230 V
  • Output power
  • 900 W
  • Output power capacity
  • 1.6 kVA
  • Output voltage regulation
  • 10%
  • Response time
  • 6 ms
  • Surge energy rating
  • 273 J
  • UPS topology
  • Line-Interactive
  • Waveform
  • Sine
  • Logistics data
  • Harmonized System (HS) code
  • 85078000
  • Operational conditions
  • Operating altitude
  • 0 - 3000 m
  • Operating relative humidity (H-H)
  • 0 - 95%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage temperature (T-T)
  • -15 - 40 °C
  • Packaging data
  • Cables included
  • Input power cable
  • Manual
  • Y
  • Ports & interfaces
  • AC outlet types
  • C13 coupler
  • AC outlets quantity
  • 6 AC outlet(s)
  • Ethernet LAN (RJ-45) ports
  • 2
  • Power plug
  • C13 coupler
  • USB 2.0 ports quantity
  • 1
  • USB port
  • Y
  • USB port type
  • USB Type-B
  • Technical details
  • Sustainability certificates
  • RoHS
  • Weight & dimensions
  • Depth
  • 390 mm
  • Height
  • 190 mm
  • Package depth
  • 390 mm
  • Package height
  • 190 mm
  • Package weight
  • 11.3 kg
  • Package width
  • 140 mm
  • Weight
  • 10.3 kg
  • Width
  • 140 mm
