Model: C9200CX-12T-2X2G-E

Cisco C9200CX-12T-2X2G-E network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE)

Manufacturer:
Cisco
Cisco C9200CX-12T-2X2G-E, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

Cisco C9200CX-12T-2X2G-E. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 15, Installed SFP+ modules quantity: 2, USB 2.0 ports quantity: 1. MAC address table: 32000 entries, Switching capacity: 35 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power over Ethernet (PoE). Rack mounting

Product Properties

  • Model
  • C9200CX-12T-2X2G-E
  • Data transmission
  • MAC address table
  • 32000 entries
  • Switching capacity
  • 35 Gbit/s
  • Design
  • Rack mounting
  • Y
  • Stackable
  • Y
  • Management features
  • Quality of Service (QoS) support
  • Y
  • Switch type
  • Managed
  • Multicast features
  • Multicast MAC address table
  • 1000 entries
  • Multicast support
  • Y
  • Network
  • 10G support
  • Y
  • Networking standards
  • IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
  • Performance
  • Mean time between failures (MTBF)
  • 755270 h
  • Ports & interfaces
  • Compatible memory cards
  • SD
  • Installed SFP+ modules quantity
  • 2
  • Switch Number of Ports
  • 15
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • USB 2.0 ports quantity
  • 1
  • Power
  • Power source
  • DC/PoE
  • Power supply included
  • Y
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Y
  • Security
  • Access Control List (ACL)
  • Y
  • IGMP entries
  • 1000
  • IGMP snooping
  • Y
  • Security algorithms
  • 256-bit AES
  • Weight & dimensions
  • Depth
  • 165 mm
  • Height
  • 44 mm
  • Weight
  • 1.81 kg
  • Width
  • 269 mm
