Model: C9300X-12Y-E

Cisco Catalyst 9300X Managed L3

Manufacturer:
Cisco
Cisco Catalyst 9300X, Managed, L3, Rack mounting
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

Cisco Catalyst 9300X. Switch type: Managed, Switch layer: L3. MAC address table: 32000 entries. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Rack mounting

Product Properties

  • Model
  • C9300X-12Y-E
  • Data transmission
  • Jumbo frames
  • 9198
  • Jumbo frames support
  • Yes
  • MAC address table
  • 32000 entries
  • Design
  • LED indicators
  • Yes
  • Rack mounting
  • Yes
  • Stackable
  • Yes
  • Logistics data
  • Harmonized System (HS) code
  • 85176990
  • Management features
  • Switch layer
  • L3
  • Switch type
  • Managed
  • Network
  • 10G support
  • Yes
  • Networking standards
  • IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
  • Operational conditions
  • Operating relative humidity (H-H)
  • 5 - 90%
  • Operating temperature (T-T)
  • -5 - 45 °C
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Ports & interfaces
  • QSFP28 ports quantity
  • 12
  • Power
  • AC input frequency
  • 50 - 60 Hz
  • AC input voltage
  • 100 - 230 V
  • Power consumption (typical)
  • 715 W
  • Power supply included
  • Yes
  • Weight & dimensions
  • Depth
  • 409 mm
  • Height
  • 43.9 mm
  • Width
  • 445 mm
