Cisco MA-SFP-1GB-LX10 network transceiver module Fiber optic 1000 Mbit/s
Roll over image to zoom inClick to Open expanded view
Print
Model: MA-SFP-1GB-LX10

Cisco MA-SFP-1GB-LX10 network transceiver module Fiber optic 1000 Mbit/s

Manufacturer:
Cisco
Cisco MA-SFP-1GB-LX10, Fiber optic, 1000 Mbit/s, SFP, LC, 9/125 µm, LX
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

Cisco MA-SFP-1GB-LX10. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Certification: MSA. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm

Product Properties

  • Model
  • MA-SFP-1GB-LX10
  • Features
  • Certification
  • MSA
  • Hot-Plug support
  • Yes
  • Logistics data
  • Harmonized System (HS) code
  • 85369010
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 80%
  • Operating temperature (T-T)
  • 0 - 70 °C
  • Storage relative humidity (H-H)
  • 10 - 85%
  • Storage temperature (T-T)
  • -40 - 85 °C
  • Performance
  • Auto MDI/MDI-X
  • Yes
  • Cabling technology
  • 1000BASE-LX10
  • Fiber cable diameters supported (core/cladding)
  • 9/125 µm
  • Fiber optic connector
  • LC
  • Interface type
  • SFP
  • Maximum data transfer rate
  • 1000 Mbit/s
  • Networking standards
  • IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
  • SFP transceiver standard
  • LX
  • SFP transceiver type
  • Fiber optic
  • Single-mode fiber (SMF) supported
  • Yes
  • Weight & dimensions
  • Depth
  • 56.5 mm
  • Height
  • 8.5 mm
  • Width
  • 13.4 mm
