D-Link DGS-1100-26MPV2 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Roll over image to zoom inClick to Open expanded view
D-Link DGS-1100-26MPV2 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
D-Link DGS-1100-26MPV2 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Print
Model: DGS-1100-26MPV2
EAN: 790069453342

D-Link DGS-1100-26MPV2 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Manufacturer:
D-Link
D-Link DGS-1100-26MPV2, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

D-Link DGS-1100-26MPV2. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 52 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1w, IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting
  • Simple Layer 2 Management
  • Web-based User Interface
  • PoE options up to 370W power budget
  • Limited-Lifetime Warranty after registration

Product Properties

  • Model
  • DGS-1100-26MPV2
  • EAN
  • 790069453342
  • Bullet points
  • Point
  • Limited-Lifetime Warranty after registration
    PoE options up to 370W power budget
    Simple Layer 2 Management
    Web-based User Interface
  • Data transmission
  • Forwarding rate
  • 38.69 Mpps
  • Jumbo frames support
  • Yes
  • MAC address table
  • 8000 entries
  • Switching capacity
  • 52 Gbit/s
  • Design
  • Housing material
  • Metal
  • Product colour
  • Black
  • Rack mounting
  • Yes
  • Logistics data
  • Harmonized System (HS) code
  • 85176990
  • Management features
  • ARP inspection
  • Yes
  • MIB support
  • • RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC1907 SNMPv2 MIB • RFC1215 MIB Traps Convention
  • Quality of Service (QoS) support
  • Yes
  • Switch layer
  • L2
  • Switch type
  • Managed
  • Web-based management
  • Yes
  • Multicast features
  • IPv4 multicast entries
  • 1
  • IPv6 multicast entries
  • 1
  • Multicast support
  • Yes
  • Number of multicast groups filtered
  • 1
  • Network
  • Auto MDI/MDI-X
  • Yes
  • Auto-negotiation
  • Yes
  • Broadcast storm control
  • Yes
  • Copper ethernet cabling technology
  • 10GBASE-T, 1000BASE-T
  • Flow control support
  • Yes
  • Full duplex
  • Yes
  • Half duplex
  • Yes
  • Head-of-line (HOL) blocking
  • Yes
  • Link aggregation
  • Yes
  • Networking standards
  • IEEE 802.1D, IEEE 802.1w, IEEE 802.3af, IEEE 802.3at
  • Port mirroring
  • Yes
  • Rate limiting
  • Yes
  • Spanning tree protocol
  • Yes
  • Virtual LAN features
  • Port-based VLAN, Voice VLAN
  • VLAN support
  • Yes
  • Operational conditions
  • Heat dissipation
  • 287 BTU/h
  • Operating relative humidity (H-H)
  • 0 - 95%
  • Operating temperature (T-T)
  • -10 - 50 °C
  • Storage relative humidity (H-H)
  • 0 - 95%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Performance
  • Fanless
  • Yes
  • Flash memory
  • 16 MB
  • MTBF (PoE)
  • 317.777 h
  • Noise level
  • 50.5 dB
  • Ports & interfaces
  • Combo SFP ports quantity
  • 2
  • Switch Number of Ports
  • 24
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power
  • AC input frequency
  • 50 - 60 Hz
  • AC input voltage
  • 100 - 240 V
  • Power consumption (max)
  • 454.1 W
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet (PoE) ports quantity
  • 24
  • Power over Ethernet plus (PoE+) ports quantity
  • 24
  • Total Power over Ethernet (PoE) budget
  • 370 W
  • Protocols
  • IPv4 & IPv6 features
  • IPv4 FIB
  • Security
  • DHCP features
  • DHCP client
  • IGMP snooping
  • Yes
  • MAC address filtering
  • Yes
  • Security algorithms
  • SSL/TLS
  • Static port security
  • Yes
  • Weight & dimensions
  • Depth
  • 208 mm
  • Height
  • 44 mm
  • Weight
  • 2.8 kg
  • Width
  • 440 mm
