Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Roll over image to zoom inClick to Open expanded view
Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black
Print
Model: GP-AP850GM-UK
EAN: 4719331550967

Gigabyte Aorus P850W power supply unit 850 W 20+4 pin ATX ATX Black

Manufacturer:
Gigabyte
Gigabyte Aorus P850W, 850 W, 100 - 240 V, 47 - 63 Hz, 10 A, Active, 120 W
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

Gigabyte Aorus P850W. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, Cabling type: Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Width: 150 mm, Depth: 160 mm, Height: 86 mm
  • Fully Modular Design
  • High quality 100% Japanese Capacitors
  • 135mm 2 ball bearing smart fan with fan stop function
  • 80 PLUS Gold certified: above 90% efficiency at 50% load
  • Single +12V rail
  • OCP/OTP/OVP/OPP/UVP/SCP protection

Product Properties

  • Model
  • GP-AP850GM-UK
  • EAN
  • 4719331550967
  • Bullet points
  • Point
  • 135mm 2 ball bearing smart fan with fan stop function
    80 PLUS Gold certified: above 90% efficiency at 50% load
    Fully Modular Design
    High quality 100% Japanese Capacitors
    OCP/OTP/OVP/OPP/UVP/SCP protection
    Single +12V rail
  • Design
  • Cooling type
  • Active
  • Fan diameter
  • 13.5 cm
  • Fan location
  • Top
  • Number of fans
  • 1 fan(s)
  • On/off switch
  • Y
  • Product colour
  • Black
  • Performance
  • 80 PLUS certification
  • 80 PLUS Gold
  • ATX version
  • 2.31
  • Bearing technology
  • Ball bearing
  • Mean time between failures (MTBF)
  • 100000 h
  • Power supply unit (PSU) form factor
  • ATX
  • Purpose
  • PC
  • Ports & interfaces
  • ATX power connector (20+4 pin)
  • Y
  • Cabling type
  • Modular
  • CPU power connector (4+4 pin)
  • Y
  • Floppy disk drive connector
  • Y
  • Floppy drive power connector
  • 2
  • Motherboard power cable length
  • 65 cm
  • Motherboard power connector
  • 20+4 pin ATX
  • Number of SATA power connectors
  • 6
  • PCI Express connector
  • Y
  • PCI Express power connectors (6+2 pin)
  • 6
  • Peripheral (Molex) power connectors (4-pin)
  • 5
  • Power
  • AC input frequency
  • 47 - 63 Hz
  • AC input voltage
  • 100 - 240 V
  • Combined power (+12V)
  • 846 W
  • Combined power (+3.3V)
  • 120 W
  • Combined power (+5V)
  • 120 W
  • Combined power (+5Vsb)
  • 15 W
  • Combined power (-12V)
  • 3.6 W
  • Efficiency
  • 90%
  • Hold time
  • 16 ms
  • Input current
  • 10 A
  • Max output current (+12V)
  • 70.5 A
  • Max output current (+3.3V)
  • 20 A
  • Max output current (+5V)
  • 20 A
  • Max output current (+5Vsb)
  • 3 A
  • Max output current (-12V)
  • 0.3 A
  • Power factor
  • 0.9
  • Power Factor Correction (PFC) type
  • Active
  • Power Good signal delay range
  • 100 - 150 ms
  • Power protection features
  • Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
  • Total power
  • 850 W
  • Weight & dimensions
  • Depth
  • 160 mm
  • Height
  • 86 mm
  • Width
  • 150 mm
