Intel Core i5-12500 processor 18 MB Smart Cache Box
Roll over image to zoom inClick to Open expanded view
Print
Model: BX8071512500
EAN: 5032037238564

Intel Core i5-12500 processor 18 MB Smart Cache Box

Manufacturer:
Intel
Intel Core i5-12500, Intel® Core™ i5, LGA 1700, Intel, i5-12500, 64-bit, 12th gen Intel® Core™ i5
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

Intel Core i5-12500. Processor family: Intel® Core™ i5, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, Workstation, PCI Express slots version: 5.0, 4.0. Package type: Retail box

Product Properties

  • Model
  • BX8071512500
  • EAN
  • 5032037238564
  • Features
  • Commodity Classification Automated Tracking System (CCATS)
  • G167599
  • CPU configuration (max)
  • 1
  • Direct Media Interface (DMI) Revision
  • 4.0
  • Embedded options available
  • No
  • Execute Disable Bit
  • Yes
  • Export Control Classification Number (ECCN)
  • 5A992CN3
  • Idle States
  • Yes
  • Market segment
  • Desktop
  • Maximum number of PCI Express lanes
  • 20
  • PCI Express configurations
  • 1x16+1x4, 2x8+1x4
  • PCI Express slots version
  • 5.0, 4.0
  • Scalability
  • 1S
  • Supported instruction sets
  • SSE4.1, SSE4.2, AVX 2.0
  • Thermal Monitoring Technologies
  • Yes
  • Use conditions
  • PC/Client/Tablet, Workstation
  • Graphics
  • Discrete graphics card
  • No
  • Discrete graphics card model
  • Not available
  • Multi-Format Codec Engines
  • 2
  • Number of displays supported (on-board graphics)
  • 4
  • Number of execution units
  • 32
  • On-board graphics card
  • Yes
  • On-board graphics card base frequency
  • 300 MHz
  • On-board graphics card DirectX version
  • 12.0
  • On-board graphics card dynamic frequency (max)
  • 1450 MHz
  • On-board graphics card ID
  • 0x4690
  • On-board graphics card maximum resolution (DisplayPort)
  • 7680 x 4320 pixels
  • On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
  • 5120 x 3200 pixels
  • On-board graphics card maximum resolution (HDMI)
  • 4096 x 2160 pixels
  • On-board graphics card model
  • Intel UHD Graphics 770
  • On-board graphics card OpenGL version
  • 4.5
  • On-board graphics card outputs supported
  • Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
  • On-board graphics card refresh rate at maximum resolution (DisplayPort)
  • 60 Hz
  • On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
  • 120 Hz
  • On-board graphics card refresh rate at maximum resolution (HDMI)
  • 60 Hz
  • Logistics data
  • Harmonized System (HS) code
  • 85423119
  • Memory
  • ECC
  • Yes
  • Maximum internal memory supported by processor
  • 128 GB
  • Memory bandwidth (max)
  • 76.8 GB/s
  • Memory channels
  • Dual-channel
  • Memory types supported by processor
  • DDR4-SDRAM, DDR5-SDRAM
  • Operational conditions
  • Tjunction
  • 100 °C
  • Other features
  • Graphics output
  • eDP 1.4b, DP 1.4a, HDMI 2.1
  • Maximum internal memory
  • 128 GB
  • Packaging data
  • Package type
  • Retail box
  • Processor
  • Box
  • Yes
  • Bus type
  • DMI4
  • Cooler included
  • No
  • Maximum number of DMI lanes
  • 8
  • Maximum turbo power
  • 117 W
  • Memory bandwidth supported by processor (max)
  • 76.8 GB/s
  • Number of Cores
  • 6
  • Performance cores
  • 6
  • Performance-core base frequency
  • 3 GHz
  • Performance-core boost frequency
  • 4.6 GHz
  • Processor
  • i5-12500
  • Processor ARK ID
  • 96144
  • Processor base power
  • 65 W
  • Processor boost frequency
  • 4.6 GHz
  • Processor cache
  • 18 MB
  • Processor cache type
  • Smart Cache
  • Processor codename
  • Alder Lake
  • Processor family
  • Intel® Core™ i5
  • Processor generation
  • 12th gen Intel® Core™ i5
  • Processor manufacturer
  • Intel
  • Processor operating modes
  • 64-bit
  • Processor socket
  • LGA 1700
  • Processor threads
  • 12
  • Processor special features
  • Enhanced Intel SpeedStep Technology
  • Yes
  • Intel 64
  • Yes
  • Intel Stable Image Platform Program (SIPP)
  • Yes
  • Intel Trusted Execution Technology
  • Yes
  • Intel Turbo Boost Max Technology 3.0
  • No
  • Intel Virtualization Technology (VT-x)
  • Yes
  • Intel Virtualization Technology for Directed I/O (VT-d)
  • Yes
  • Intel vPro® Enterprise Platform Eligibility
  • Yes
  • Intel vPro® Essentials Platform Eligibility
  • Yes
  • Intel VT-x with Extended Page Tables (EPT)
  • Yes
  • Intel® Active Management Technology (Intel® AMT)
  • Yes
  • Intel® AES New Instructions (Intel® AES-NI)
  • Yes
  • Intel® Boot Guard
  • Yes
  • Intel® Clear Video HD Technology (Intel® CVT HD)
  • Yes
  • Intel® Control-flow Enforcement Technology (CET)
  • Yes
  • Intel® Deep Learning Boost (Intel® DL Boost)
  • Yes
  • Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
  • Yes
  • Intel® Hardware Shield Eligibility
  • Yes
  • Intel® Hyper Threading Technology (Intel® HT Technology)
  • Yes
  • Intel® One-Click Recovery
  • Yes
  • Intel® Optane™ Memory Ready
  • Yes
  • Intel® OS Guard
  • Yes
  • Intel® Quick Sync Video Technology
  • Yes
  • Intel® Secure Key
  • Yes
  • Intel® Speed Shift Technology
  • Yes
  • Intel® Standard Manageability (ISM)
  • Yes
  • Intel® Thread Director
  • No
  • Intel® Threat Detection Technology (TDT)
  • Yes
  • Intel® Total Memory Encryption
  • Yes
  • Intel® Total Memory Encryption - Multi Key
  • Yes
  • Intel® Turbo Boost Technology
  • 2.0
  • Intel® Virtualization Technology with Redirect Protection (VT-rp)
  • Yes
  • Intel® Volume Management Device (VMD)
  • Yes
  • Intel® vPro™ Platform Eligibility
  • Yes
  • Mode-based Execute Control (MBE)
  • Yes
  • Technical details
  • Launch date
  • Q1'22
  • OpenCL version
  • 2.1
  • Status
  • Launched
  • Target market
  • Gaming
  • Weight & dimensions
  • Processor package size
  • 45 x 37.5 mm
