Description

Mercusys 300Mbps Wireless N Router. Wi-Fi band: Single-band (2.4 GHz), Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 300 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11b,IEEE 802.11g,IEEE 802.11n. Security algorithms: 64-bit WEP,128-bit WEP,152-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK. Supported network protocols: IPv4. Product type: Tabletop router, Product colour: White

300Mbps wireless speed is ideal for HD streaming, online gaming, and large file downloads
Three 5dBi antennas greatly increase wireless signal strength, size and stability
Intuitive webpage guides you through the setup process in minutes

Product Properties

Manufacturer
Mercusys

Model
MW305R

EAN
6935364072537

Antenna

Antenna gain level (max)
5 dBi

Antenna type
External

Antennas quantity
2

Bullet points

Point
300Mbps wireless speed is ideal for HD streaming, online gaming, and large file downloads

Intuitive webpage guides you through the setup process in minutes

Three 5dBi antennas greatly increase wireless signal strength, size and stability

Design

Product colour
White

Product type
Tabletop router

Features

Certification
CE RoHS

Management features

Reset button
Y

Network

Ethernet LAN
Y

Ethernet LAN data rates
10,100 Mbit/s

Ethernet LAN interface type
Fast Ethernet

Networking standards
IEEE 802.11b,IEEE 802.11g,IEEE 802.11n

Port forwarding
Y

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
-40 - 70 °C

Packaging data

AC adapter included
Y

Cables included
LAN (RJ-45)

Manual
Y

Package depth
198 mm

Package height
68 mm

Package type
Box

Package weight
450 g

Package width
267 mm

Quick start guide
Y

Ports & interfaces

Memory card slot(s)
N

USB port
N

Power

Output current
0.6 A

Output voltage
5 V

Power source type
AC

Protocols

DHCP server
Y

Supported network protocols
IPv4

Universal Plug and Play (UPnP)
Y

Security

DMZ support
Y

Filtering
Y

Firewall
Y

Guest access
Y

MAC address filtering
Y

Port-based Network Access Control (PNAC)
Y

Security algorithms
64-bit WEP,128-bit WEP,152-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK

WAN connection

Ethernet WAN
Y

Weight & dimensions

Depth
115.4 mm

Height
34.7 mm

Width
168.9 mm

Wireless LAN features

Top Wi-Fi standard
Wi-Fi 4 (802.11n)

Wi-Fi band
Single-band (2.4 GHz)

Wi-Fi standards
802.11b,802.11g,Wi-Fi 4 (802.11n)

WLAN data transfer rate (max)
300 Mbit/s
