Description

Mercusys AC1200 Dual Band Wireless Router. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Security algorithms: WPA-PSK,WPA2-PSK. Product type: Tabletop router, Product colour: Black. Antenna type: External, Antenna gain level (max): 5 dBi

Supports 802.11ac standard - the next generation of Wi-Fi
Enjoy smooth online gaming and video streaming with dual band 1200Mbps Wi-Fi
4 External Antennas Greatly Expand Wireless Coverage
Guest Network Access provides secure Wi-Fi access for guests sharing your home or office network
Easy installation - intuitive webpage guides you through the setup process in minutes

Product Properties

Manufacturer
Mercusys

Model
AC12-

EAN
6935364072506

Antenna

Antenna gain level (max)
5 dBi

Antenna type
External

Antennas quantity
4

Bullet points

Point
4 External Antennas Greatly Expand Wireless Coverage

Easy installation - intuitive webpage guides you through the setup process in minutes

Enjoy smooth online gaming and video streaming with dual band 1200Mbps Wi-Fi

Guest Network Access provides secure Wi-Fi access for guests sharing your home or office network

Supports 802.11ac standard - the next generation of Wi-Fi

Design

Product colour
Black

Product type
Tabletop router

Features

Certification
CE, RoHS

Management features

Reset button
Y

Web-based management
Y

Mobile network

Network

Cabling technology
10/100Base-T(X)

Dynamic DNS (DDNS)
Y

Ethernet LAN
Y

Ethernet LAN data rates
10,100 Mbit/s

Ethernet LAN interface type
Fast Ethernet

Networking standards
IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3u

Port forwarding
Y

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
-40 - 70 °C

Packaging data

AC adapter included
Y

Cables included
LAN (RJ-45)

Package depth
288 mm

Package height
66 mm

Package weight
640 g

Package width
382 mm

Quick installation guide
Y

Ports & interfaces

Ethernet LAN (RJ-45) ports
4

Memory card slot(s)
N

USB port
N

Power

Output current
0.85 A

Output voltage
9 V

Power source type
AC

Protocols

DHCP client
Y

DHCP server
Y

Security

Access Control List (ACL)
Y

Firewall
Y

Guest access
Y

IP address filtering
Y

MAC address filtering
Y

Security algorithms
WPA-PSK,WPA2-PSK

WAN connection

3G/4G USB modem compatibility
N

DSL WAN
N

Ethernet WAN
Y

SIM card slot
N

Weight & dimensions

Depth
140 mm

Height
32 mm

Width
222 mm

Wireless LAN features

Top Wi-Fi standard
Wi-Fi 5 (802.11ac)

Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)

Wi-Fi standards
802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)

WLAN data transfer rate (max)
867 Mbit/s
