MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'
Roll over image to zoom inClick to Open expanded view
MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'
MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'
MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'
MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'
MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'
MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'
Print
Model: MPG A1000G
EAN: 4719072898755

MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'

Manufacturer:
MSI
MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU', 1000 W, 100 - 240 V, 50 - 60 Hz, 13.0/6.5 A, 1000 W, 120 W
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

MSI MPG A1000G UK PSU '1000W, 80 Plus Gold certified, Fully Modular, 100% Japanese Capacitor, Flat Cables, ATX Power Supply Unit, UK Powercord, Black, Support Latest GPU'. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX. Purpose: All-in-One PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 14 cm, Number of fans: 1 fan(s). Width: 150 mm, Depth: 86 mm, Height: 150 mm
  • Supports the NVIDIA GeForce RTX™ 30 Series GPUs
  • Full modular cable design
  • Flat cable equipment
  • 80 Plus Gold certified for high efficiency
  • 100% all Japanese 105oCcapacitor
  • Active PFC design
  • Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP
  • LLC Half Bridge Topology with DC-DC module design

Product Properties

  • Manufacturer
  • MSI
  • Model
  • MPG A1000G
  • EAN
  • 4719072898755
  • Bullet points
  • Point
  • 100% all Japanese 105oCcapacitor
    80 Plus Gold certified for high efficiency
    Active PFC design
    Flat cable equipment
    Full modular cable design
    Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP
    LLC Half Bridge Topology with DC-DC module design
    Supports the NVIDIA GeForce RTX™ 30 Series GPUs
  • Design
  • Fan diameter
  • 14 cm
  • Number of fans
  • 1 fan(s)
  • Product colour
  • Black
  • Logistics data
  • Harmonized System (HS) code
  • 84733020
  • Performance
  • 80 PLUS certification
  • 80 PLUS Gold
  • Power supply unit (PSU) form factor
  • ATX
  • Purpose
  • All-in-One PC
  • Supported motherboard form factors
  • ATX
  • Ports & interfaces
  • EPS power connector (4+4 pin)
  • Y
  • Motherboard power connector
  • 20+4 pin ATX
  • Number of SATA power connectors
  • 3
  • PCI Express power connectors (6+2 pin)
  • 2
  • Peripheral (Molex) power connectors (4-pin)
  • 4
  • Power
  • AC input frequency
  • 50 - 60 Hz
  • AC input voltage
  • 100 - 240 V
  • Combined power (+12V)
  • 1000 W
  • Combined power (+5V)
  • 120 W
  • Combined power (+5Vsb)
  • 15 W
  • Combined power (-12V)
  • 3.6 W
  • Efficiency
  • 90%
  • Input current
  • 13.0/6.5 A
  • Max output current (+12V)
  • 83.3 A
  • Max output current (+5V)
  • 22 A
  • Max output current (+5Vsb)
  • 3 A
  • Max output current (-12V)
  • 0.3 A
  • Power protection features
  • Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
  • Total power
  • 1000 W
  • Weight & dimensions
  • Depth
  • 86 mm
  • Height
  • 150 mm
  • Width
  • 150 mm
