StarTech.com 15m (50ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
Roll over image to zoom inClick to Open expanded view
StarTech.com 15m (50ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
StarTech.com 15m (50ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
StarTech.com 15m (50ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
StarTech.com 15m (50ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
Print
Model: 450FBLCLC15
EAN: 65030882439

StarTech.com 15m (50ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord

Manufacturer:
StarTech.com
StarTech.com 15m (50ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord, 15 m, OM4, LC, LC
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

StarTech.com 15m (50ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord. Cable length: 15 m, Fibre optic type: OM4, Connector 1: LC, Connector 2: LC, Core diameter: 50 µm, Full duplex
  • OM4 FIBER CABLE: OM4 Laser-Optimized Multimode Fiber Cable delivers up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors for cabling servers and Storage Area Networks (SANs)
  • QUALITY CONSTRUCTION: 50/125µm fiber core/cladding is immune to EMI; Protective Aramid fiber sheath for improved tensile strength and crush resistance; LC/LC connectors with UPC polished ceramic ferrules for insertion loss below 0.3dB
  • RATINGS AND RELIABILITY: Individually tested for signal integrity; LSZH jacket emits low-smoke and fumes if combusted; Attenuation value under 2.3dB/km meets or exceeds industry standards
  • COMPATIBILITY: OM4 LC/LC multimode cable supports 1/10/40/100 Gbps for high-density network applications such as SANs, data servers, SFP+ and QSFP+ connections over 1000BASE-SX, 10GBASE-SR, 40GBASE-SR4, and 100GBASE-SR10
  • SPECS: 15m (49ft); Color: Aqua (OM4); LC/LC UPC; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: ≥2000MHz·km at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm), Dynamic 2.4in (6cm); Backed for Life

Product Properties

  • Model
  • 450FBLCLC15
  • EAN
  • 65030882439
  • Bullet points
  • Point
  • COMPATIBILITY
    OM4 FIBER CABLE
    QUALITY CONSTRUCTION
    RATINGS AND RELIABILITY
    SPECS
  • Features
  • Cable length
  • 15 m
  • Cladding diameter
  • 125 µm
  • Connector 1
  • LC
  • Connector 1 gender
  • Male
  • Connector 2
  • LC
  • Connector 2 gender
  • Male
  • Core diameter
  • 50 µm
  • Data transfer rate
  • 100 Gbit/s
  • Fiber mode structure
  • Multi-mode
  • Fibre optic type
  • OM4
  • Full duplex
  • Yes
  • Jacket material
  • Low smoke zero halogen (LSZH)
  • Product colour
  • Aqua colour
  • Wavelengths supported
  • 850 nm
  • Logistics data
  • Harmonized System (HS) code
  • 85447000
  • Operational conditions
  • Operating temperature (T-T)
  • -20 - 60 °C
  • Storage temperature (T-T)
  • -20 - 60 °C
  • Packaging data
  • Package depth
  • 200 mm
  • Package height
  • 32 mm
  • Package weight
  • 205 g
  • Package width
  • 220 mm
  • Quantity per pack
  • 1 pc(s)
  • Technical details
  • Doesn't contain
  • Halogen
  • Sustainability certificates
  • CE, RoHS
  • Sustainability compliance
  • Yes
  • Weight & dimensions
  • Weight
  • 180 g
