Description

StarTech.com 3ft (1m) USB C to DisplayPort 1.4 Cable 8K 60Hz/4K - Bidirectional DP to USB-C or USB-C to DP Reversible Video Adapter Cable -HBR3/HDR/DSC - USB Type-C/TB3 Monitor Cable. Cable length: 1 m, Connector 1: USB Type-C, Connector 2: DisplayPort. Sustainability certificates: CE, RoHS. Weight: 46 g. Quantity per pack: 1 pc(s), Package width: 225 mm, Package depth: 125 mm. Master (outer) case width: 325 mm, Master (outer) case length: 500 mm, Master (outer) case height: 210 mm

HIGH PERFORMANCE: 3.3ft/1m reversible USB-C to DisplayPort 1.4 cable or DP to USB-C cable supports 8K 60Hz/4K 120Hz/HDR/DisplayHDR/ HBR3/Display Stream Compression (DSC)/HDCP 2.2/1.4; DisplayPort to USB-C bidirectional cord; Thunderbolt 3/4 compatible
REVERSIBLE CABLE: When connecting a USB-C computer to a DisplayPort monitor, the computer must support USB-C DisplayPort Alternative mode (DP alt-mode); When connecting a DisplayPort computer to a USB-C monitor, the monitor must have its own power supply
IMAGE QUALITY: This adapter features a unique video signal booster which amplifies the signal and ensures reliable performance, even with lower quality cables; The amplifier also increases the max. supported DP cable length compared to other brands
DP OR USB-C MONITOR COMPATIBLE: Use this DisplayPort to USB-C cable to convert from a DP host to a USB-C monitor; supports USB-C 16:9 & ultrawide monitors; NOTE: Does not support portable displays / monitors that do not have an independent power supply
INTEGRATED VIDEO ADAPTER CABLE: Supports driverless setup on any OS, minimizes failure points & signal loss, and features latching DP connector to ensure a reliable & consistent connection; NOTE: It is recommended to connect the USB-C connector first

Product Properties

Manufacturer
StarTech.com

Model
CDP2DP141MBD

EAN
65030887939

Bullet points

Point
DP OR USB-C MONITOR COMPATIBLE

HIGH PERFORMANCE

IMAGE QUALITY

INTEGRATED VIDEO ADAPTER CABLE

REVERSIBLE CABLE

Features

Cable length
1 m

Chipset
Chrontel - CH7213C-BF, Texas Instruments - TUSB544, VIA Labs - VL170

Connector 1
USB Type-C

Connector 1 form factor
Straight

Connector 1 gender
Male

Connector 2
DisplayPort

Connector 2 form factor
Straight

Connector 2 gender
Male

Converter type
Active video converter

DisplayPort version
1.4

HDCP
Yes

HDCP version
1.4/2.2

High Dynamic Range (HDR) supported
Yes

Maximum refresh rate
120 Hz

Maximum resolution
7680 x 4320 pixels

Product colour
Black

Supported audio channels
7.1

Supported graphics resolutions
3840 x 2160, 7680 x 4320

USB Type-C DisplayPort Alternate Mode
Yes

Logistics data

Harmonized System (HS) code
84733080

Master (outer) case height
210 mm

Master (outer) case length
500 mm

Master (outer) case width
325 mm

Products per master (outer) case
100 pc(s)

Operational conditions

Operating relative humidity (H-H)
10 - 85%

Operating temperature (T-T)
0 - 45 °C

Storage temperature (T-T)
-10 - 70 °C

Packaging data

Package depth
125 mm

Package height
15 mm

Package weight
50 g

Package width
225 mm

Quantity per pack
1 pc(s)

Sustainability

Sustainability certificates
CE, RoHS

Sustainability compliance
Yes

Weight & dimensions

Weight
46 g
