Model: PEXUSB312A1C1H
EAN: 65030888325

StarTech.com 5-Port USB PCIe Card - 10Gbps USB 3.1 Gen 2 PCIe Card w/ 1x USB-C & 2x USB-A - 1x 2 Port IDC (Internal 5Gbps USB Header Expansion) - USB C PCI Express Controller Card

Manufacturer:
StarTech.com
StarTech.com 5-Port USB PCIe Card - 10Gbps USB 3.1 Gen 2 PCIe Card w/ 1x USB-C & 2x USB-A - 1x 2 Port IDC (Internal 5Gbps USB Header Expansion) - USB C PCI Express Controller Card, PCIe, USB 3.2 Gen 2 (3.1 Gen 2), PCIe 3.0, Red, 1677495 h, ASMedia - ASM31
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

StarTech.com 5-Port USB PCIe Card - 10Gbps USB 3.1 Gen 2 PCIe Card w/ 1x USB-C & 2x USB-A - 1x 2 Port IDC (Internal 5Gbps USB Header Expansion) - USB C PCI Express Controller Card. Host interface: PCIe, Output interface: USB 3.2 Gen 2 (3.1 Gen 2), Expansion card standard: PCIe 3.0. Product colour: Red, Mean time between failures (MTBF): 1677495 h. Chipset: ASMedia - ASM3142, Genesys Logic - GL3590, Data transfer rate (max): 10 Gbit/s. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Mac operating systems supported: Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur,..., Server operating systems supported: Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2019. Width: 68.9 mm, Depth: 102 mm, Height: 14.4 mm
  • HIGH PERFORMANCE: 5-Port USB PCIe card with ASMedia 3142 IC; 10Gbps Hub w/ 3 External Ports (2x USB-A & 1x USB-C) & two internal ports USB 5Gbps (1x Internal IDC header); Supports up to USB 3.2/3.1 Gen 2; Upgraded version to our popular card PEXUSB312EIC
  • TRANSFER SPEEDS UP TO 10Gbps: USB-A & USB-C PCIe card adapter supports Multiple INs maintaining max bandwidth with mixed speed devices and UASP optimizing USB performance with external storage devices like SSDs, HDDs, NVMe drives; Works w/ USB 3.1/3.0/2.0
  • OPTIONAL POWER: USB PCIe expansion card with SATA power supplies supplemental power to the USB ports (when motherboard power is insufficient) providing up to 5V 3A/15W via the USB Type-C port & 5V 0.9A/4.5W via each USB port
  • COMPATIBILITY: USB C add-on card installs in full or low-profile PCIe 3.0 (x4 slot) desktop/server (full-profile bracket installed, low profile bracket incl.); lower performance with PCI-e 2.0; Windows/Linux/macOS auto driver install (Windows 8 & up)
  • STARTECH.COM ADVANTAGE: IT professionals choice for over 30 years; This USB-A & USB-C combo PCI Express Host Controller card is backed for 2-years by StarTech.com, including free 24/5 North America based multi-lingual tech support

Product Properties

  • Model
  • PEXUSB312A1C1H
  • EAN
  • 65030888325
  • Bullet points
  • Point
  • COMPATIBILITY
    HIGH PERFORMANCE
    OPTIONAL POWER
    STARTECH.COM ADVANTAGE
    TRANSFER SPEEDS UP TO 10Gbps
  • Design
  • Internal
  • Yes
  • Mean time between failures (MTBF)
  • 1677495 h
  • Product colour
  • Red
  • Features
  • Chipset
  • ASMedia - ASM3142, Genesys Logic - GL3590
  • Data transfer rate (max)
  • 10 Gbit/s
  • UASP support
  • Yes
  • Logistics data
  • Harmonized System (HS) code
  • 84733020
  • Master (outer) case height
  • 500 mm
  • Master (outer) case length
  • 375 mm
  • Master (outer) case width
  • 370 mm
  • Products per master (outer) case
  • 60 pc(s)
  • Operational conditions
  • Operating relative humidity (H-H)
  • 15 - 90%
  • Operating temperature (T-T)
  • 0 - 70 °C
  • Storage temperature (T-T)
  • -20 - 80 °C
  • Packaging data
  • Mounting brackets included
  • Yes
  • Package depth
  • 175 mm
  • Package height
  • 30 mm
  • Package weight
  • 125 g
  • Package width
  • 140 mm
  • Quick installation guide
  • Yes
  • Ports & interfaces
  • Expansion card standard
  • PCIe 3.0
  • Host interface
  • PCIe
  • Internal SATA ports quantity
  • 1
  • Output interface
  • USB 3.2 Gen 2 (3.1 Gen 2)
  • USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
  • 2
  • USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
  • 1
  • System requirements
  • Mac operating systems supported
  • Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura
  • Windows operating systems supported
  • Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
  • Server operating systems supported
  • Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2019
  • Technical details
  • Sustainability certificates
  • CE, RoHS
  • Weight & dimensions
  • Depth
  • 102 mm
  • Height
  • 14.4 mm
  • Weight
  • 60 g
  • Width
  • 68.9 mm
