StarTech.com 7m (22ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
Roll over image to zoom inClick to Open expanded view
StarTech.com 7m (22ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
StarTech.com 7m (22ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
StarTech.com 7m (22ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
StarTech.com 7m (22ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord
Print
Model: 450FBLCLC7
EAN: 65030881821

StarTech.com 7m (22ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord

Manufacturer:
StarTech.com
StarTech.com 7m (22ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord, 7 m, OM4, LC, LC
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

StarTech.com 7m (22ft) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable, 50/125µm LOMMF/VCSEL Zipcord Fiber, 100G Networks, Low Insertion Loss, LSZH Fiber Patch Cord. Cable length: 7 m, Fibre optic type: OM4, Connector 1: LC, Connector 2: LC, Core diameter: 50 µm, Full duplex
  • OM4 FIBER CABLE: OM4 Laser-Optimized Multimode Fiber Cable delivers up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors for cabling servers and Storage Area Networks (SANs)
  • QUALITY CONSTRUCTION: 50/125µm fiber core/cladding is immune to EMI; Protective Aramid fiber sheath for improved tensile strength and crush resistance; LC/LC connectors with UPC polished ceramic ferrules for insertion loss below 0.3dB
  • RATINGS AND RELIABILITY: Individually tested for signal integrity; LSZH jacket emits low-smoke and fumes if combusted; Attenuation value under 2.3dB/km meets or exceeds industry standards
  • COMPATIBILITY: OM4 LC/LC multimode cable supports 1/10/40/100 Gbps for high-density network applications such as SANs, data servers, SFP+ and QSFP+ connections over 1000BASE-SX, 10GBASE-SR, 40GBASE-SR4, and 100GBASE-SR10
  • SPECS: 7m (23ft); Color: Aqua (OM4); LC/LC UPC; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: ≥2000MHz·km at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm), Dynamic 2.4in (6cm); Backed for Life

Product Properties

  • Model
  • 450FBLCLC7
  • EAN
  • 65030881821
  • Bullet points
  • Point
  • COMPATIBILITY
    OM4 FIBER CABLE
    QUALITY CONSTRUCTION
    RATINGS AND RELIABILITY
    SPECS
  • Features
  • Cable length
  • 7 m
  • Cladding diameter
  • 125 µm
  • Connector 1
  • LC
  • Connector 1 gender
  • Male
  • Connector 2
  • LC
  • Connector 2 gender
  • Male
  • Core diameter
  • 50 µm
  • Data transfer rate
  • 100 Gbit/s
  • Fiber mode structure
  • Multi-mode
  • Fibre optic type
  • OM4
  • Full duplex
  • Yes
  • Jacket material
  • Low smoke zero halogen (LSZH)
  • Product colour
  • Aqua colour
  • Wavelengths supported
  • 850 nm
  • Logistics data
  • Harmonized System (HS) code
  • 85447000
  • Master (outer) case height
  • 450 mm
  • Master (outer) case length
  • 410 mm
  • Master (outer) case width
  • 410 mm
  • Products per master (outer) case
  • 120 pc(s)
  • Operational conditions
  • Operating temperature (T-T)
  • -20 - 60 °C
  • Storage temperature (T-T)
  • -20 - 60 °C
  • Packaging data
  • Package depth
  • 200 mm
  • Package height
  • 15 mm
  • Package weight
  • 104 g
  • Package width
  • 220 mm
  • Quantity per pack
  • 1 pc(s)
  • Technical details
  • Doesn't contain
  • Halogen
  • Sustainability certificates
  • RoHS, CE
  • Sustainability compliance
  • Yes
  • Weight & dimensions
  • Weight
  • 94 g
