StarTech.com Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 10/100/1000 Mbps - RJ-45 100m - Cisco Meraki MS225, MX400, MS250
Roll over image to zoom inClick to Open expanded view
Model: MASFP1GBTXST
EAN: 65030869461

StarTech.com Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 10/100/1000 Mbps - RJ-45 100m - Cisco Meraki MS225, MX400, MS250

Manufacturer:
StarTech.com
StarTech.com Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 10/100/1000 Mbps - RJ-45 100m - Cisco Meraki MS225, MX400, MS250, Copper, 1000 Mbit/s, SFP, TX, 100 m, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

StarTech.com Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 10/100/1000 Mbps - RJ-45 100m - Cisco Meraki MS225, MX400, MS250. SFP transceiver type: Copper, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Product colour: Silver, Housing material: Aluminium, Mean time between failures (MTBF): 4655371 h. Power consumption (typical): 1.3 W. Width: 18 mm, Depth: 68 mm, Height: 13.8 mm. Number of products included: 1 pc(s), Package width: 118 mm, Package depth: 93 mm
  • 100% CISCO MERAKI MA-SFP-1GB-TX COMPATIBLE: Works with Cisco Meraki switches like MS225, MX400, MS250, MS350, MX84 and others
  • TECHNICAL SPECS: 10BASE-T / 1 Gbps / Copper / RJ-45 Connector / Distances up to 100m (328ft)
  • TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in Cisco routers and switches
  • WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
  • THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance.

Product Properties

  • Model
  • MASFP1GBTXST
  • EAN
  • 65030869461
  • Bullet points
  • Point
  • 100% CISCO MERAKI MA-SFP-1GB-TX COMPATIBLE
    TECHNICAL SPECS: 10BASE-T / 1 Gbps / Copper / RJ-45 Connector / Distances up to 100m (328ft)
    TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in Cisco routers and switches
    THE IT PRO’S CHOICE
    WORKS WITH MSA COMPLIANT SWITCHES
  • Features
  • Hot-Plug support
  • Yes
  • Housing material
  • Aluminium
  • Mean time between failures (MTBF)
  • 4655371 h
  • Product colour
  • Silver
  • Logistics data
  • Harmonized System (HS) code
  • 85369010
  • Master (outer) case height
  • 205 mm
  • Master (outer) case length
  • 305 mm
  • Master (outer) case width
  • 260 mm
  • Products per master (outer) case
  • 36 pc(s)
  • Operational conditions
  • Operating relative humidity (H-H)
  • 5 - 95%
  • Operating temperature (T-T)
  • 0 - 70 °C
  • Storage temperature (T-T)
  • -40 - 85 °C
  • Packaging data
  • Number of products included
  • 1 pc(s)
  • Package depth
  • 93 mm
  • Package height
  • 35 mm
  • Package weight
  • 51 g
  • Package width
  • 118 mm
  • Performance
  • Auto MDI/MDI-X
  • Yes
  • Auto-negotiation
  • Yes
  • Digital Diagnostics Monitoring (DDM)
  • No
  • Duplex system
  • Full
  • Ethernet LAN
  • Yes
  • Ethernet LAN (RJ-45) ports
  • 1
  • Interface type
  • SFP
  • Maximum data transfer rate
  • 1000 Mbit/s
  • Maximum transfer distance
  • 100 m
  • Networking standards
  • IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
  • SFP transceiver standard
  • TX
  • SFP transceiver type
  • Copper
  • Power
  • Power consumption (typical)
  • 1.3 W
  • Technical details
  • Sustainability certificates
  • CE, RoHS
  • Weight & dimensions
  • Depth
  • 68 mm
  • Height
  • 13.8 mm
  • Weight
  • 21 g
  • Width
  • 18 mm
