Description

TP-Link 5-Port 2.5G Desktop Switch with 4-Port PoE++. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 4000 entries, Switching capacity: 25 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power over Ethernet (PoE)

5× 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps RJ45 ports
With four PoE++ ports, transfers data and power on one single cable
Works with IEEE 802.3af/at/bt type3 compliant PDs
802.1p/DSCP QoS enable smooth latency-sensitive traffic
Supports PoE Power up to 60 W for each PoE++ port
Supports PoE Power up to 123 W for all PoE ports*
PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
Plug and Play, no configuration and installation required

Product Properties

Manufacturer
TP-LINK

Model
TL-SG105PP-M2

EAN
4895252501148

Bullet points

Point
5× 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps RJ45 ports

802.1p/DSCP QoS enable smooth latency-sensitive traffic

Plug and play, no configuration and installation required

Supports PoE Power up to 123 W for all PoE ports*

Supports PoE Power up to 60 W for each PoE++ port

With four PoE++ ports, transfers data and power on one single cable

Works with IEEE 802.3af/at/bt type3 compliant PDs

Data transmission

Forwarding rate
18.6 Mpps

MAC address table
4000 entries

Store-and-forward
Yes

Switching capacity
25 Gbit/s

Design

Certification
CE, FCC, RoHS

Housing material
Steel

LED indicators
Yes

Product colour
Black

Rack mounting
No

Management features

Quality of Service (QoS) support
Yes

Switch type
Unmanaged

Network

10G support
No

Auto MDI/MDI-X
Yes

Auto-negotiation
Yes

Cable types supported
Cat3, Cat4, Cat5, Cat5e

Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T

Flow control support
Yes

MAC address auto-aging supported
Yes

MAC address auto-learning supported
Yes

Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x

Operational conditions

Heat dissipation
488.89 BTU/h

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
-40 - 70 °C

Packaging data

Cables included
AC

Package type
Box

User guide
Yes

Performance

Fanless
Yes

Ports & interfaces

2.5G Ethernet (copper) ports quantity
5

Switch Number of Ports
5

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

AC input frequency
50 Hz

AC input voltage
220 V

Input current
2.43 A

Input voltage
53.5 V

Number of power supply units
1

Power consumption (max)
143.37 W

Power source
DC/PoE

Power supply included
Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes

Power over Ethernet (PoE) power per port
60 W

Power over Ethernet 4PPoE (PoE++) ports quantity
4

Total Power over Ethernet (PoE) budget
123 W

Security

IGMP snooping
Yes

Weight & dimensions

Depth
126 mm

Height
26 mm

Width
209 mm
