Description

TP-Link AV2000 2-Port Gigabit Passthrough Powerline Starter Kit. Maximum data transfer rate: 2000 Mbit/s, Networking standards: IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, Ethernet LAN interface type: Gigabit Ethernet. Power consumption (typical): 5.8 W, Power consumption (standby): 0.5 W. Product colour: White, LED indicators: LAN, PLC, Power, Certification: CE. Windows operating systems supported: Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64,..., Mac operating systems supported: macOS. Width: 130.7 mm, Depth: 71.7 mm, Height: 42 mm

HomePlug AV2 standard compliant, high-speed data transfer rates of up to 2000Mbps1, supports all your online needs
2X2 MIMO with Beamforming establishes multiple simultaneous connections for you to enjoy higher powerline speeds and greater stability
2 gigabit ports create secure wired networks for desktops, smart TVs or games consoles
Integrated power socket ensures no power outlet goes to waste
Plug and play, no configuration required
Patented Power-Saving Mode automatically reduces power consumption by up to 85%

Product Properties

Manufacturer
TP-LINK

Model
TL-PA9020PKIT

EAN
6935364094799

Bullet points

Point
2 gigabit ports create secure wired networks for desktops, smart TVs or games consoles

Integrated power socket ensures no power outlet goes to waste

Patented Power-Saving Mode automatically reduces power consumption by up to 85%

Plug and play, no configuration required

Design

Certification
CE

LED indicators
LAN, PLC, Power

Product colour
White

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
-40 - 70 °C

Packaging content

Cables included
LAN (RJ-45)

Quantity per pack
2 pc(s)

Quick installation guide
Y

Performance

Built-in power socket
Y

Encryption button
Y

Ethernet LAN
Y

Ethernet LAN (RJ-45) ports
2

Ethernet LAN data rates
10,100,1000 Mbit/s

Ethernet LAN interface type
Gigabit Ethernet

Maximum data transfer rate
2000 Mbit/s

Maximum operating distance
300 m

Modulation
OFDM

Networking standards
IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u

Plug and Play
Y

PowerLine standard
HomePlug AV2

Quality of Service (QoS) support
Y

Security algorithms
128-bit AES

Power

Power consumption (standby)
0.5 W

Power consumption (typical)
5.8 W

System requirements

Linux operating systems supported
Y

Mac compatibility
Y

Mac operating systems supported
macOS

Windows operating systems supported
Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home

Technical details

Sustainability certificates
RoHS

Weight & dimensions

Depth
71.7 mm

Height
42 mm

Package depth
190 mm

Package height
100 mm

Package weight
780 g

Package width
230 mm

Width
130.7 mm
