TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point
Roll over image to zoom inClick to Open expanded view
TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point
TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point
TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point
Print
Model: EAP230-WALL
EAN: 6935364089498

TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point

Manufacturer:
TP-LINK
TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point, 1167 Mbit/s, 300 Mbit/s, 867 Mbit/s, 10,100,1000 Mbit/s, 2.4 - 5 GHz, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point. Maximum data transfer rate: 1167 Mbit/s, Maximum data transfer rate (2.4 GHz): 300 Mbit/s, Maximum data transfer rate (5 GHz): 867 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, SNMP, SNMPv2, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK, Service Set Identifier (SSID) features: Multiple SSIDs. WAN connection: Ethernet (RJ-45). Power consumption (typical): 9 W, Power consumption (max): 25.5 W. Placement: Wall, Product colour: White, LED indicators: Operation
  • Fast Dual-Band Wi-Fi: Simultaneous 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz totals 1,167 Mbps Wi-Fi speeds with MU-MIMO.†
  • Gigabit Ports: 2 Gigabit Ethernet ports (1× uplink + 1× downlink)
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)‡, Centralized Cloud Management, and Intelligent Monitoring
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management
  • Private Connection for Every Room: Designed to meet every network need in environments with numerous separated rooms, like hotels, offices, and dormitories
  • Elegant Appearance: Unprecedented thin design with just 11 mm, the same size and shape as a light switch or power outlet faceplate to fit perfectly in any room
  • Easy Installation and PoE Support: Easy-mount construction, compatible with 86 mm & EU standard junction box, and 802.3af/at PoE support
  • Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies

Product Properties

  • Model
  • EAP230-WALL
  • EAN
  • 6935364089498
  • Antenna
  • Antenna features
  • Integrated antenna
  • Antenna gain level (max)
  • 3.6 dBi
  • Antenna type
  • Internal
  • Antennas quantity
  • 2
  • Bullet points
  • Point
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management
    Easy Installation and PoE Support
    Elegant Appearance
    Fast Dual-Band Wi-Fi
    Gigabit Ports: 2 Gigabit Ethernet ports (1× uplink + 1× downlink)
    Integrated into Omada SDN
    Private Connection for Every Room
    Secure Guest Network
  • Design
  • LED indicators
  • Operation
  • Placement
  • Wall
  • Product colour
  • White
  • Reset button
  • Yes
  • Features
  • 2.4 GHz
  • Yes
  • 5 GHz
  • Yes
  • 6 GHz
  • No
  • Automatic channel scanning
  • Yes
  • Automatic channel selection
  • Yes
  • Band steering
  • Yes
  • BeamForming
  • Yes
  • Cabling technology
  • 10/100/1000Base-T(X)
  • Ethernet LAN data rates
  • 10,100,1000 Mbit/s
  • Frequency band
  • 2.4 - 5 GHz
  • Maximum data transfer rate
  • 1167 Mbit/s
  • Maximum data transfer rate (2.4 GHz)
  • 300 Mbit/s
  • Maximum data transfer rate (5 GHz)
  • 867 Mbit/s
  • MIMO
  • Yes
  • MIMO type
  • Multi User MIMO
  • Networking standards
  • IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
  • Quality of Service (QoS) support
  • Yes
  • Rate limiting
  • Yes
  • Transmitting power (CE)
  • 20 - 23 dBm
  • Virtual LAN features
  • Port-based VLAN, VLAN mapping
  • VLAN support
  • Yes
  • Wi-Fi Multimedia (WMM)/(WME)
  • Yes
  • Logistics data
  • Harmonized System (HS) code
  • 85176990
  • Management features
  • Syslog
  • Yes
  • Web-based management
  • Yes
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Packaging content
  • Mounting kit
  • Yes
  • Number of products included
  • 2 pc(s)
  • Quick start guide
  • Yes
  • Packaging data
  • Package depth
  • 130 mm
  • Package height
  • 47 mm
  • Package weight
  • 210 g
  • Package width
  • 118 mm
  • Performance
  • Compatible operating systems
  • Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
  • Ports & interfaces
  • Ethernet LAN (RJ-45) ports
  • 1
  • WAN connection
  • Ethernet (RJ-45)
  • Power
  • Power consumption (max)
  • 25.5 W
  • Power consumption (typical)
  • 9 W
  • Power over Ethernet (PoE)
  • Yes
  • Protocols
  • Secure File Transfer Protocol (SFTP) using SSH v2
  • Yes
  • Security
  • Access Control List (ACL)
  • Yes
  • MAC address filtering
  • Yes
  • Number of SSID supported
  • 16
  • Security algorithms
  • 64-bit WEP, 128-bit WEP, 152-bit WEP, SNMP, SNMPv2, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
  • Service Set Identifier (SSID) features
  • Multiple SSIDs
  • Sustainability
  • Sustainability certificates
  • CE, RoHS
  • Sustainability compliance
  • Yes
  • Weight & dimensions
  • Depth
  • 86.8 mm
  • Height
  • 30.2 mm
  • Width
  • 86.8 mm
