Model: TL-SX3016F
EAN: 6935364006440

TP-Link TL-SX3016F network switch Managed L2/L2+ Black

Manufacturer:
TP-LINK
TP-Link TL-SX3016F, Managed, L2/L2+, Rack mounting
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

TP-Link TL-SX3016F. Switch type: Managed, Switch layer: L2/L2+. Console port: RJ-45/Micro-USB. MAC address table: 32000 entries, Switching capacity: 320 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE.... Power connector: DC-in jack. Rack mounting
  • 16× Full 10GE SFP+ Slots: Lightning-fast full 10 Gbps SFP+ slots provide high-bandwidth aggregation connectivity and non-blocking 320 Gbps switching capacity
  • Abundant L2 and L2+ Features: Supports a complete lineup of L2 and L2+ features including Static Routing, enterprise-level QoS, IGMP Snooping, and more
  • Robust Security Strategies: Helps protect LAN area investment with integrated IP-MAC-Port Binding, ACL, Port Security, 802.1X Authentication, and more
  • Dual Redundant Power Supplies: Two power supplies backing each other up make it an ideal choice for reliable networking architecture
  • Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management
  • Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities

Product Properties

  • Model
  • TL-SX3016F
  • EAN
  • 6935364006440
  • Bullet points
  • Point
  • 16× Full 10GE SFP+ Slots
    Abundant L2 and L2+ Features
    Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management
    Dual Redundant Power Supplies
    Robust Security Strategies
    Standalone Management
  • Data transmission
  • Forwarding rate
  • 238.08 Mpps
  • Jumbo frames
  • 9000
  • Jumbo frames support
  • Yes
  • MAC address table
  • 32000 entries
  • Number of queues
  • 8
  • Static route
  • Yes
  • Switching capacity
  • 320 Gbit/s
  • Design
  • Certification
  • CE, FCC, RoHS
  • LED indicators
  • Yes
  • Product colour
  • Black
  • Rack mounting
  • Yes
  • Logistics data
  • Harmonized System (HS) code
  • 85176990
  • Management features
  • ARP inspection
  • Yes
  • Cloud-managed
  • Yes
  • Configuring Location Settings (CLI)
  • Yes
  • MIB support
  • RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213
  • Quality of Service (QoS) support
  • Yes
  • Switch layer
  • L2/L2+
  • Switch type
  • Managed
  • System event log
  • Yes
  • Traffic classification
  • Yes
  • Web-based management
  • Yes
  • Multicast features
  • Multicast Listener Discovery (MLD) snooping
  • Y
  • Multicast support
  • Yes
  • Network
  • 10G support
  • Yes
  • Broadcast storm control
  • Yes
  • Flow control support
  • Yes
  • Head-of-line (HOL) blocking
  • Yes
  • IP routing
  • Yes
  • Link aggregation
  • Yes
  • Networking standards
  • IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3x
  • Number of VLANs
  • 4000
  • Port mirroring
  • Yes
  • Rate limiting
  • Yes
  • Spanning tree protocol
  • Yes
  • Virtual LAN features
  • Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
  • VLAN support
  • Yes
  • Operational conditions
  • Heat dissipation
  • 111.71 BTU/h
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • 0 - 45 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Packaging data
  • Cables included
  • AC
  • Manual
  • Yes
  • Package depth
  • 336 mm
  • Package height
  • 100 mm
  • Package type
  • Box
  • Package weight
  • 3.7 kg
  • Package width
  • 528 mm
  • Quick start guide
  • Yes
  • Rack mount kit
  • Yes
  • Ports & interfaces
  • Console port
  • RJ-45/Micro-USB
  • Power connector
  • DC-in jack
  • SFP+ module slots quantity
  • 16
  • Switch Port Speed
  • No
  • Power
  • AC input frequency
  • 50 - 60 Hz
  • AC input voltage
  • 100 - 240 V
  • Power consumption (max)
  • 32.74 W
  • Power source
  • AC
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • No
  • Protocols
  • IPv4 & IPv6 features
  • IPv6 Telnet, IPv6 ping, IPv6 tracert
  • Management protocols
  • SNMPv1/v2c/v3, SNTP
  • Security
  • Access Control List (ACL)
  • Yes
  • Authentication
  • Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication
  • Authentication type
  • AAA, TACACS+
  • BPDU filtering/protection
  • Yes
  • DHCP features
  • DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
  • IGMP snooping
  • Yes
  • IP-MAC-Port binding
  • Yes
  • Loop protection
  • Yes
  • MAC address filtering
  • Yes
  • Queue scheduling algorithms
  • SP, WRR+SP, Weighted Round Robin (WRR)
  • Security algorithms
  • HTTPS, SSH, SSH-2, SSL/TLS
  • SSH/SSL support
  • Yes
  • Static port security
  • Yes
  • Weight & dimensions
  • Depth
  • 220 mm
  • Height
  • 44 mm
  • Width
  • 440 mm
